Reference: 2365
WLL: 1500 - 6000 kg
Gripping range: 100 - 430 mm
Screw clamp for HP profile NL-H
- Suspension of profiles type HP.
- Complies with the provisions of the Machinery Directive: 2006/42/WE
- Made according to the harmonized standard: PN-EN 13155
Marked on product : producers sign, sign CE, load capacity, factory number, year of production.
CODE | WLL [kg] |
Gripping range HP [mm] |
Dimensions [mm] |
Mass [kg] |
|||||||||
A | B | C | ØD | E | G | H | L | T | W | ||||
NL-H 1.5 | 1 500 | 100-240 | 154 | 165 | 40 | 27 | 22,5 - 46 | 75 | 177 | 191 - 211 | 75 | 67 | 5,6 |
NL-H 3.0 | 3 000 | 160-320 | 170 | 221 | 45 | 32 | 29 - 60 | 65 | 184 | 250 - 275 | 74 | 74 | 10,5 |
NL-H 6.0 | 6 000 | 300-430 | 190 | 260 | 60 | 25 | 54 - 82,5 | 85 | 224 | 306 - 340,5 | 89 | 105 | 14,5 |
